Acl Implants

Acl Implants Overview

Achieve strong, reliable cortical fixation in anterior cruciate ligament reconstruction with our advanced fixation button systems. Designed as premium acl implants for orthopedic surgeons, these devices provide secure suspensory fixation for both soft tissue and bone-tendon-bone grafts. The suture button fixation technique enables reproducible graft tensioning and minimizes tunnel widening, supporting accelerated rehabilitation protocols. Whether for primary or revision ACL surgery, our implants deliver the mechanical strength and ease of use required for optimal patient outcomes.

Acl Implants Features

• High‑Strength Alloy Construction: The button is machined from medical‑grade titanium alloy, offering exceptional pullout strength and fatigue resistance. This robust material ensures the fixation button maintains its integrity throughout the healing process, reducing the risk of implant failure.

• Low‑Profile, Smooth Design: The streamlined contour and polished surface minimize soft tissue irritation and facilitate smooth passage through bone tunnels. Surgeons benefit from reduced friction during graft passage, preserving graft integrity.

• Color‑Coded Suture System: Integrated high‑strength sutures are color‑coded for clear identification of pulling, flipping, and loop functions. This feature simplifies the surgical workflow, allowing precise deployment and tensioning of the suture button fixation construct.

• Adjustable Loop Technology: The continuous UHMWPE loop can be precisely shortened to accommodate varying graft lengths and tunnel depths. This adaptability ensures optimal graft fill within the tunnel, promoting better biological incorporation.

• Versatile Graft Compatibility: Compatible with hamstring, quadriceps, and bone‑tendon‑bone grafts, our acl implants offer a single‑solution approach to most ACL reconstructions, reducing inventory complexity while maintaining surgical flexibility.

Certifications & Compliance

• CE Mark (EU): Certified under Medical Device Regulation (EU) 2017/745.

• ISO 13485: Manufactured in facilities compliant with international quality management standards.

Detailed Technical Parameters

• Fixation Type: Extracortical suspensory fixation

• Graft Types: Soft tissue (hamstring, quadriceps), bone‑tendon‑bone, quad tendon‑bone

• Suture Configuration:

  • Loop Suture: Continuous UHMWPE loop, adjustable via suture‑only mechanism

  • Pulling Suture: #2 UHMWPE, braided, color‑coded blue

  • Flipping Suture: #2 UHMWPE, braided, color‑coded white

• Mechanical Performance:

  • Ultimate Tensile Strength: > 1200 N (for 20 mm loop)

  • Cyclic Displacement: < 2 mm after 1000 cycles (50‑250 N)

• Tunnel Compatibility: Accommodates 4.5 mm to 6.0 mm femoral sockets

• Sterilization Method: Ethylene oxide (EO)

After‑Sales & Warranty Policy

• Warranty Period: All acl implants are warranted against manufacturing defects for a period of five years from the date of shipment.

• Technical Support: Our clinical specialists are available to provide surgical technique guides, cadaveric training support, and remote assistance for product selection and implantation.

• Replacement Policy: Defective or damaged devices will be replaced at no cost upon verification. For unused, sterile‑packaged products, returns are accepted within 30 days of delivery subject to restocking fees.

• Custom Orders: Minimum order quantities (MOQ) and lead times for custom loop lengths or suture configurations are available upon request.

WELL TRUST advantages

1. Full certification: CE, ISO:13485, Free Sale Certificate

2. Rich experienced in manufacturing and exportation since 2005.

3. 3-7 days delivery for most product models with regular stock.

4. Resonable price: more competitive than competitors, gives the credit to strict and high efficient team management.

5. ODM & OEM service support for most of product lines .6. Rapidly developing distribution network and comprehensive after-sales service.
